Railway Angle Cock

Name: Railway Angle Cock
Brand: IVOTECK
SKU: TRC-17

90° lever operation with open / close mechanical position lock Automatic residual air exhaust under closed status Ductile iron body, anti‑vibration for railway under‑car service Certified per TB/T 2697‑2021 for brake main line cut‑off

Request a Quote Reach Our Team

Specifications

Product NameAngle cock

Product CategoryManual brake pipe shut-off valve

Product ModelTRC-17

Implementation StandardTB/T 2697‑2021

Applicable scenarioEnd of main brake pipe of locomotive, passenger car, and freight car

Rated working pressure1.0 MPa (10 bar)

Design pressure1.25 MPa

Valve body strength test pressure1.875 MPa

Gas tightness test pressure1.0 MPa

Sealing materialLow-temperature resistant NBR (Nitrile Butadiene Rubber)

Operation modeManual 90° rotation handle

Closing functionAutomatically exhaust residual air from hose side at closed position

Operating torque5‑15 N·m

Nominal diameterDN32

Opening and closing life≥50,000 cycles

Valve body materialDuctile iron QT450‑10

Valve core elementHemispherical plug / Ball plug

Connection typeExternal taper pipe thread

Connection specificationRc1¼ (DN32)

Installation formFixed installation on vehicle body flange base

Working environment temperature-40°C to +70°C

Vibration and shock standardGB/T 21563

Protection levelIP65

Factory inspectionStrength test, air tightness test, operation performance inspection

Key Features

90° lever operation with open / close mechanical position lock

Automatic residual air exhaust under closed status

Ductile iron body, anti‑vibration for railway under‑car service

Certified per TB/T 2697‑2021 for brake main line cut‑off

Product Description

Angle cock is a manual cut‑off stop valve for railway brake main pipelines, manufactured to TB/T 2697‑2021 industry standard.

The valve body adopts high‑strength ductile cast iron.
90‑degree lever operation provides two mechanical locking positions: fully‑open and fully‑closed.

At closed position, built‑in exhaust function automatically releases residual air pressure on hose side, to ensure safety during vehicle coupling and uncoupling operations.
The wear‑resistant plug core maintains stable sealing performance under heavy vehicle vibration.

Thread ports match standard brake main pipe and brake hose coupling.
Each angle cock completes strength and air‑tightness test before delivery.
It complies with GB/T 21563 shock & vibration standard, suitable for ‑40℃ ~ +70℃ working environment on locomotives, passenger cars and freight wagons.
